제품 세부 정보
원래 장소: 창주
브랜드 이름: Shengman
인증: CE
모델 번호: 엘지
지불 및 배송 조건
최소 주문 수량: 1세트
가격: USD30,000-300,000
포장 세부 사항: 내보내기 패키지
배달 시간: 30-90일
지불 조건: 티/티
공급 능력: 1-10sets/월
용량: |
고객이 요구하는 |
선택 기기: |
마이크로 피더 장치 |
공급자: |
중국 공장 |
제어 시스템: |
PLC |
부분품: |
유명 브랜드 |
먹이는 유형: |
수평공급형 |
특징: |
물과 용제 없음 |
보증: |
1년 |
재료: |
SS304, 316L |
핵심 판매 지점: |
유명 브랜드 PLC |
해당 산업: |
제약, 화학, 식품 산업 |
장점: |
엄격한 프로세스 요구 사항 |
용량: |
고객이 요구하는 |
선택 기기: |
마이크로 피더 장치 |
공급자: |
중국 공장 |
제어 시스템: |
PLC |
부분품: |
유명 브랜드 |
먹이는 유형: |
수평공급형 |
특징: |
물과 용제 없음 |
보증: |
1년 |
재료: |
SS304, 316L |
핵심 판매 지점: |
유명 브랜드 PLC |
해당 산업: |
제약, 화학, 식품 산업 |
장점: |
엄격한 프로세스 요구 사항 |
Antioxidants Roller Compactor Double Roller Granulator Without Water Or Solvent
Description of Roller Compactor:
Dry Granulator is a new type of efficient granulation equipment, which is widely used in the production of heat and humidity sensitive drugs. The main body and working part are set separately. All parts in contact with materials are easy to be disassembled and cleaned. The application of a variety of advanced technologies greatly improves the scope of materials, the quality of granules and the yield of finished products. All the design and functions of the machine are compliant with cGMP and CFR21 part11.
| Model | LG100 | LG100E | LG160 | LG200 | LG240 | LG360 |
|
Capacity (kg/h) |
1.5-15 | 12-40 | 50-150 | 100-240 | 160-320 | 360-720 |
|
Rated power (kw) |
3.47 | 3.53 | 7.24 | 11.37 | 15.94 | 32.55 |
| Roller size (D*W) | 100*25 | 100*40 | 160*50 | 200*75 | 240*100 | 360*150 |
For large production scale application, we provide double-supporting roller model
| Model | LGS200 | LGS240 | LGS360 | LGS500 |
|
Capacity (kg/h) |
200-400 | 300-640 | 1200-2000 | 1500-3000 |
|
Rated power (kw) |
||||
| Roller size (D*W) |
Key components of dry granulation machine
Feeding system: It consists of an horizontal screw feeder, which ensures continuous, stable, and uniform feeding of material into the compression roller area. It is crucial for maintaining uniform tablet density.
Compaction roller system: This is a core component, which often featuring specific patterns (such as diamond, striped) or a smooth surface, to enhance the grip and alter the tablet pressing characteristics.
Hydraulic system: It provides and precisely controls the substantial pressure applied between the two compaction rollers.
Milling (granulation) system: It consists of a crusher and a milling (granulation) device, which determines the final granule size and distribution.
Control system: Dry granulation machine utilizes PLC & touch screen control. It features precise adjustment of parameters such as feeding speed, roller pressure, roller speed (linear speed), and granulator speed.
Main adjustment parameters: Roller pressure, roller gap, feeding speed, and granulation screen mesh size. These parameters collectively determine the density, strength, output, and granularity of the granules.
Features of roller compactor:
1. Double screw extrusion feed system, high efficiency.
2. County equation roll design for easy replacement and cleaning.
3. Motor running speed and silver gap pressure can be adjusted.
4. Select a variety of rolls according to the nature of the material.
5. Through the wall installation, reduce the floor area, improve the level of clean area.
6. The breathing plate system effectively degasses the material and improves the yield.
